Xaoc Devices Samara features:
– Four attenuation channels
– Two offset channels
– Four inverters
– One four-channel mixer
– Two double-channel mixers
– Mixing of up to eight signals when using inverted inputs
– Minimum/maximum selection circuit
– Basic waveshaping

Xaoc Devices Samara, Model of 1962, is an Utility Waveform Processor, a “Swiss Army Knife” type of eurorack module, intended to serve the most common voltage and audio signal processing purposes such as attenuation, offsetting, mixing, inverting, and even basic waveshaping.

Xaoc Devices Samara features four channels—each with two inputs and an attenuator, additional switchable offset generators, four voltage level and polarity indicators, two adders with switchable scale, and a precision four-channel processor that selects minimum and maximum voltage.

Technical details:
– Eurorack synth compatible
– 10hp, skiff friendly
– Current draw: +25mA/-20mA
– Reverse power protection
